Unipower 48V negative DPG1U-A2-B2-c-f 42-60VDC psu
Unipower 48V Negative DPG1U-A2-B2-C-F 42-60VDC PSU
Panel Capacity ......................................................... 80A Per Bus 160A Total
Configuration ........................................................... Single Bus with 10 Fuses
.................................................... Dual Bus with 10 Fuses Each
Fuse Type ............................................................................................... GMT
Fuse Capacity 1 ............................................................................... A to 12A
Voltage 2 48V Version ..................................................................... 42-60VDC
24V Version ...................................................................... 21-30VDC
12V Version ................................................................... 10.5-15VDC
Polarity 2 .............................................................. Negative Ground
Alarm Indicator .......................................................... Dual-Color LED Per Bus
LED Status Indication ............................................................. Green = Normal
................................................................. Red = Alarm
............................................................. Off = No Power
Alarm Connections ................................ Two Form C Relay Contacts Per Bus
SAFETY STANDARDS ................... UL1950 CSA22.2 No.950 EN60-950
Operating Temp. Range .......................................................... -10 C to +70 C
Storage Temp. Range ............................................................ -40 C to + 85 C
Humidity ............................................................ 0% to 95% Non-Condensing
Case Material .......................................................................................... Steel
Finish ................................................................................. Powder Coat Gray
Dimensions Inches (mm) ...................................... 1.75 H x 19.00 W x 9.00 D
Weight .............................................................................. 8.38 lbs. ( 3.80kg.)
Rack Mounting Width ............................................................ 19 or 23 Inches
Input Connections .......................................... Crimp Type Lug or - 20 Stud
Output Connections ..................................................... Barrier Terminal Strips
Chassis Ground Connection ..................................................... No. 8-32 Stud
Fail Alarm Connections .............................................. .045 sq. Wirewrap Pins
