Clairtronic 0-6 0-6V 6VA l/p encap.transformer (rc)


http:// /Electrical-Power/Transformers/Encapsulated-Transformers/Approved-low-profile-encapsulated-transformers/35854/kw/88-3050#techspec
A twin primary 115V + 115V low profile transformers.
* The twin primary construction is based on twin double section bobbins (4 coil structure) which provides the maximum isolation and achieves a low interwinding capacitance
* Radiated noise and temperature rise is low
* Mechanical security to the printed circuit board is provided by 4 self tapping screws (No.6 x 9.5mm) using holes moulded in to the corners of the case
* Designed, tested, approved and certified to EN60950, CSA22.2, UL 506 and also CE marked
* The transformers are vacuum filled with UL 94-V0 resin



Clairtronic 0-6 0-6V 6VA l/p encap.transformer (rc)
