Ao smith fan condenser heat pump refrigeration motor
AO Smith Fan Condenser Heat Pump Refrigeration Motor
AO Smith Fan Condenser Heat Pump Refrigeration Motor, PSC, 1/3 HP, 1075, 460v, 48
This is New. It has a 6" shaft, and is approx. 11" in total length.
1-Phase High-Ambient Condenser Fan Motors
PSC motors are insulated and designed for troublefree operation at full rated load at high temperature.
Rotor cores have corrosion-resistant coating to ensure long motor life. Easy-to-remove drain plugs in each end shield. Shell has predrilled holes for easy Rheem mounting (mounting screws included). 36" color-coded, high-temp. leads. UL Recognized and CSA Certified.
Uses: Outdoor air conditioning and refrigeration condensing units and heat pumps.
Condenser Fan Motor, Permanent Split Capacitor, Totally Enclosed Air-Over, 1/3 HP, Number of Speeds 1, Nameplate RPM 1075, NEMA/IEC Frame 48, Voltage 460, 60 Hz, Full Load Amps 1.3, Stud Mounting, Auto Thermal Protection, Insulation Class F, Service Factor 1.0, Double-shielded Ball Bearings, Ambient 70 C, CW/CCW Rotation, Length Less Shaft 5 1/4 In, Shaft Dia 1/2 In, Shaft Length 6 In, Body Dia 5 5/8 In
ItemCondenser Fan MotorMotor TypePermanent Split CapacitorEnclosureTotally Enclosed Air-OverHP1/3Number of Speeds1Nameplate RPM1075NEMA/IEC Frame48YVoltage460Hz60Phase1Full Load Amps1.3MountingStudThermal ProtectionAutoInsulation ClassFService Factor1.0BearingsDouble-Shielded BallAmbient (C)70RotationCW/CCWLength Less Shaft (In.)5-1/4Shaft Dia. (In.)1/2Shaft Length (In.)6Body Dia. (In.)5-5/8Stud Quantity4Stud Pattern (In.)3 5/8 x 3 5/8Stud Size (In.)8-32 x 7/8, 8-32 x 9/16Nominal Efficiency69.0%Shaft OrientationUp/DownLead Length (In.)27DutyContinuous Air-OverCapacitor Required2MDV6RPM Range1000-1380StandardsUL Recognized (E46412), CSA Certified (LR43341)Mfr. Stock No.FEH1036SF
PLEASE SEE BOTTOM OF LISTING FOR MORE PICTURES
WHAT YOU SEE IS WHAT YOU GET!!!!! IF IT IS NOT PICTURED THEN ASSUME IT IS NOT THERE!!
California Residents Pay 9.25% Sales Tax.
* DO NOT DISCARD PACKAGING UNTIL CLAIM IS COMPLETED!
The products that we typically sell are:
1. Overstock (inventory clearance - unused - new) items
2. Demo model (most likely sat on the shelf for display) items.
3. Store returned (open box - possibly lightly used) items.
4. Occasionally we obtain used items (we will clearly indicate if we obtain this as a used item)
We will do our best to indicate which one of these categories the items fall into and accurately describe the item. In most cases the only thing wrong with the item is that it does not have all or any of its original packaging, maybe a scuff mark or two, or may be missing something. Owners manuals may or may not be included - usually they will be pictured or listed if they are.
PLEASE E-MAIL me with any questions you may have
