20" sansei ss-5E rotary surface grinder, 1969
20" SANSEI SS-5E ROTARY SURFACE GRINDER, 1969
20" SANSEI "JAPANESE" HORIZONTAL SPINDLE
MODEL: SS-5E S/N: 2391-5 NEW: 1969
DIAMETER OF MAGNETIC CHUCK .............. 19- 3/4"
MAX. WORK HEIGHT UNDER A NEW WHEEL ...... 5- 7/8"
SWING INSIDE TABLE GUARDS ............... 23- 1/2"
MAX. TABLE VERTICAL TRAVEL .............. 7- 7/8"
TABLE SWIVEL FROM HORIZONTAL ............ +/- 3 DEG.
TABLE SPEEDS, INFINITELY VARIABLE ....... 30 TO 200 RPM
FEED RATE (PER GRAD.) ................... 0.0001"
AUTOMATIC FEED (10 STEPS) ............... 0.0001" TO .001"
MAX. RAM HORIZONTAL TRAVEL .............. 11"
RAM SPEED, INFINITELY VARIABLE .......... 12" TO 108" IPM
GRINDING SPINDLE SPEEDS (2) ............. 1900 & 2800 RPM
GRINDING WHEEL SIZE ..................... 12" X 2" X 5"
MINIMUM GRINDING WHEEL DIAMETER ......... 9- 7/8"
SMALL FOOTPRINT ................... 83" X 34"W MACHINE ONLY
HYDRAULIC UNIT DIMS. ................ 24"L-R x 36" x 36"H
COOLANT SYSTEM DIMS. ................ 16"L-R x 31" x 24"H
APPROX. WEIGHT .......................... 5,400 LBS.
19- 3/4" FINE-DIVISION CONCENTRIC POLE
W/"ELECTRO-MATIC" VARIABLE HOLD NEUTROFIER CONTROL
HYDRAULIC OPERATION FOR TABLE SPEEDS & RAM RECIPROCATION
HYDRAULIC POWER OVER-THE-WHEEL WHEEL DRESSER
TABLE TILTS +/- 3 DEGREES FOR CONVEX/CONCAVE GRINDING
7.5. KW (10 H.P.) 3/60/220-440 VOLT GRINDING SPINDLE MOTOR
COOLANT TANK WITH MAGENTIC SEPERATOR
VERY RECENT HYDRAULIC SYSTEM WITH 5 H.P. MOTOR
