Mastech MS8040 bench model multimeter
Mastech MS8040 BENCH MODEL MULTIMETER
* 22000 counts autorange / manual range, measurement rates of 2, 20 timers/second slow, fast .
* The max overload protective voltage is up to AC 250 V (TRMS)except for current and voltage.
* In A/mA mode, protective current is 0.3A; In A mode, protective current is 10A
* Fuse : 0.3A/250V( A/mA terminal), 10A/250V(A terminal), 0.1A/250V(line power fuse
* Optical Isolution RS232C Interface.
* Operating Temperature: 18 28 (relative humidity <=80%)
* Storage Temperature: 20 60 (relative humidity <=80%)
* Temperature Coefficient: 0.05 Specified Accuracy per (<18 or >28 )
* Dimensions: 238mm(W) 230mm(L) 83mm(H)
* Weight : Approx. 1.5kg, without power cord
Above accuracies for film capacitor or better can be guaranteed within the full range.
Above specification from 20nF to 2uF ranges are specified under REL mode. The reading is calibrated to zero by relative function when input is floating.
