2005 kubota KX61-2 mini excavator track hoe 1336 hours
2005 Kubota KX61-2S Super Series Excavator 1,336 Hours
Deluxe suspension seat with arm rest.
2-pattern selection system. Allows the opeator to select either ISO or SAE operating control pattern by changing the position of the "A-B" lever.
Photo of the oil fill tube with the cap removed and the engine running at idle. No blow-by was observed.
Photos of the right side undercarriage and rubber track.
Photos of the left side undercarriage and rubber track.
Click on the link below to view a video walk around of this machine: http:// /watch?v=DbsLn4N_WrA
Kubota D1105-EBH-6, 68.5 cubic inch displacement, 3-cylinder diesel engine with 27 horsepower.
19.4 gallons per minute hydraulic pump capacity.
11.9 gallons per minute auxiliary hydraulic line flow rate.
2,743 lbs. maximum bucket breakout force.
Maximum drawbar pull: 5,875 lbs.
Blade width x height: 55.1" X 12.5"
Blade maximum lift above ground level: 13.8"
Blade maximum drop below ground: 13.6"
Fuel tank capacity: 7.4 gallons.
Coolant capacity: 1.0 gallons.
Engine oil capacity: 1.2 gallons.
Hydraulic oil capacity: 9.2 gallons.
Two pattern selection system: Change from ISO or SAE Control pattern by repositioning the "A-B" lever.
Bucket cylinder hoses are routed through the arm. This protects them from damage which ensures a longer service life, reduces repair costs and improves operator visibility.
Reinforced boom cylinder protection: The V-shaped guard provides greater protection to the boom cylinder.
Tapered track frame: The top of the track frame is tapered 30 degrees in order to minimize the accumulation of work site materials in the track. The tapered frame contributes to increased track life.
Improved track tension spring improves shock loads to tracks and increases the life of the tracks.
Complete rear end protection: The counter weight provides maximum rear end protection. When working in confined areas an operator can feel confident that the large side and rear counterweight bumpers will protect the engine compartment form damage.
The diesel engine cranks easily and runs smoothly. The undercarriage, rubber tracks and drive system appear to be in good conditon and are operating correctly. The boom and dipperstick appear to be straight and true. There are no welds and the wear in these components is consistent with the hours on the machine. The battery appears to be several years old and may need to be replaced in the near future. The engine is due to be serviced.
For a complimentary delivery quote anywhere in the Continental U.S., please contact Load'em Up Freight Brokers at (***) 569-5623 or email them at ****@loademup.net The machine transport dimensions are:
Approximate weight: 6,110 lbs.
No sales tax for non-commercial purchasers outside of Georgia.
Out of State commercial purchasers, add $100.00 Georgia Heavy Duty Motor Vehicle Tax.
Please call for information on finance options.
