Stepper motor controller driver board bipolar dual mode
Stepper Motor Controller Driver Board Bipolar Dual Mode
Brand new Stepper Motor Controller and Driver Board with 2 control modes available.
You can either control the motor with pulses and signals or by using the on-board buttons.
This industrial designed product is ideal for many uses. Perfect for student experiments, prototypes, or just DIY projects.
* Matching motors: 6 wires or 4 wires stepper motor (2-phase)
* Voltage (stepper motor): 9-40VDC
* Motor speed adjustable and can be retained
* Common Empty if 6-wire motor
Pulse and Signal Control Mode:
* Input pulse: CP (can adjust step motor speed)
* Directional signal: DIR (high voltage=INC; low voltage=DEC)
* With jumper JP2 mounted: INC=CW run, DEC=CCW run, FUN=Stop
* With jumper JP2 removed: INC=Accelerate, DEC=Decellerate, FUN=Speed memory
* (If you mount jumper JP2 after speed adjustment it will be memorized, even when power is off)
* Dimensions: Width 46mm (1.8in), Length 70mm (2.7in), Height 30mm (1.2in)
