New eaton ghb smart breaker ghbs-1015D novar
GBHS circuit breakers are bolt-on branch circuit breakers designed for use in panelboards and are ideally suited for lighting control applications. In addition to providing conventional branch circuit protection, they include a unique solenoid-operated mechanism that provides for efficient breaker pulse-on and pulse-off operation when used with a suitable controller like the Cutler-Hammer Pow-R-Command lighting control system or Novar NCH-1000.
* Bolt-on Line-Side Terminal
* Cable Connected Load-Side Terminal
* 3-Prong Control Terminal (Common, Solenoid, Auxiliary Switch)
* Bi-Metal Assembly for Thermal Overload Protection
* Fast Acting Short Circuit Protection
* Arc-Runner and Arc-Chute Assembly for Fast Acting Arc Extinction
* Three Position Handle: OFF, TRIP (Center), ON
* Handle in ON Position Enables Remote Control
* Handle in OFF Position Disables Remote Control
* Handle Permits Manual Switching When Control Power is Lost
* Mechanical Trip Indicator Window (Red-ON, Green-OFF/TRIPPED)
* 15 and 20 Ampere Breakers SWD (Switching Duty) Rated
* HID Ratings for HID (High Intensity Discharge) Lighting
Breakers are new and have not been energized.
