New * * allen bradley 1784-PCM4 /b 1784PCM4 cable DH485
Rockwell Automation > PLC & HMI > I/O Products > PLC-5 > 1784-PCM4/B
Allen-Bradley 1784-PCM4 DH485 RJ45 Communication Cable for use with 1784-PCMK Series B PCMCIA Communication Card, Series B
1784-PCM4 Series B cable connects 1784-PCMK Series B PCMCIA ard to an SLC 5/01, 5/02, or 5/03 processor, 1747-AIC link coupler for DH485 communication or other DH485 devices with an RJ45 jack. Total cable length: 10.4 ft (3.16 m); Length from PCMK card connector to pod: 7 in. (17.8 cm); Length from pod to processor: 9.2 ft (2.8 m).
When 1784-PCMK Series B card connected directly to the processor, the DH485 link can have only two nodes: the slc processor and the notebook computer with the 1784-PCMK card installed. In order to use the 1784-PCMK card on a DH485 link with more than two nodes the 1784-PCMK card must be connected through a 1747-AIC link coupler.
One New Open Box Allen Bradley 1784-PCM4 Series B, DH485 RJ45 Communication Cable for use with 1784-PCMK Series B PCMCIA Communication Card.
