Caterpillar 631 633 tractor scraper service manual cat
ENGINE the different manuals included in this section are:
Service Manual for 5.4 Bore Six Cylinder Vehicle Engine (Cylinder Block Spacer Plate) 51 pages long.
Engine Specifications for 5.4 Bore Six Cylinder Vehicle Engine (Cylinder Block Spacer Plate 28 pages long.
POWER TRAIN the different manuals included in this section are:
Service Manual 631C, 633C & 637 Tractor Power Train 32 pages long.
Transmission Hydraulic Controls 15 pages long. Also in the corner of the first page is the following: 631C: 67M1-Up; 633C: 66M1-Up; 637: 65M1-Up; 79P1-Up.
VEHICLE SYSTEMS - the different manuals included in this section are:
Service Manual Air/Oil Suspension Seat 37 pages long.
Coach and Car Airdraulic Seat System 27 pages long. This is for Use in Tractor-Scraper Manuals: 621B, REG01532, 623B, REG01607; 627B, REG01609; 631C & 633C, REG00672; 637, REG00700; 641B, 650B, 651B & 660B, REG00629; 657B & 666B, REG00626.
Service Manual 631-637-641-651-657 Steering System (Hydraulic Follow-Up) 22 pages long.
Service Manual 631C-633C-637 Steering System (Mechanical Follow-Up) 15 pages long.
Service Manual 633 Steering System (Hydraulic Follow-Up) 14 pages long.
Steering System (Hydraulic Follow-Up Specifications for 633 Tractor-Scraper Serial Numbers 66M1-Up and 86H341-Up 8 pages long.
Service Manual 631-633-641-650-651-660 Air System and Brakes 22 pages long.
Systems Operation Testing and Adjusting Scraper Hydraulic System (631C; 637; 641B; 650B; 651B; 657B; 660B; 666B Scrapers 15 pages long.
Specifications for 631C, 637, 641B, 650B, 651B, 657B, 660B, and 666B Scraper Hydraulic System 15 pages long.
Flow Meter Tee Test Procedure looks like it is missing the front covers 2 sections each 8 pages long.
Service Manual Flow Meter Tee Test Procedure VIII 12 pages long.
Service Manual 633C Scraper Hydraulic System 22 pages long.
Hydraulic System Specifications for 633C Scraper Serial Numbers Tractor: 66M1-Up, Scraper: 86H341-Up 19 pages long.
Flow Meter Tee Test Procedure pages 17 pages long no front cover.
Service Manual Flow Meter Tee Test Procedure X 18 pages long;
Service Manual 631C-637, 641B 651B 657B Cushion-Hitch 17 pages long.
Cushion-Hitch Specifications for 631C, 637, 641B, 651B, 657B Tractors. Serial Numbers: 65K1-UP; 65M1-UP; 67K1-UP; 67M1-UP; 68K1-UP; 79P1-UP 11 pages long.
Service Manual 633 Cushion-Hitch 21 pages long.
Cushion Hitch Specifications for 633 Tractor, Serial Number 66M 9 pages long.
DISASSEMBLY & ASSEMBLY - the different manuals included in this section are:
Disassembly and Assembly General Instructions 21 pages long.
Air Compressors Tu-Flo 300, 400, 500, 501 & 1000 Compressors 43 pages long.
Caterpillar Special Instructions 15 pages long.
Service Manual Disassembly and Assembly Brake Rotochambers 15 pages long.
Service Manual Disassembly and Assembly 631, 633, 637 Tractor Engine 77 pages long.
Service Manual Disassembly and Assembly 631, 633, 637 Tractor Power Train 103 pages long.
Service Manual Disassembly and Assembly 631, 633, 637 Tractor Vehicle Systems 30 pages long.
Service Manual Disassembly and Assembly 633 Scraper Vehicle Systems 63 pages long.
Please note that there is a Lubrication and Maintenance Section but there is nothing behind the tab this part is missing. There are nice black and white illustrations and pictures throughout the manual. If you own one of these types of equipment, here s a valuable manual to have!
