24VDC hydraulic trailer kit to lift 10 tonne 800MM
24vdc Hydraulic Trailer / Tipper Kit To Lift 10 Tonne 800mm - ZZ000757
This all in one hydraulic trailer kit consists of the following, easy to assemble, components which will allow you to lift a weight of up to 10 tonnes to a height of 800mm
* 24vdc single acting powerpack complete with 2 button pendant.
* 600mm stroke single acting cylinder.
* 3 metres of hydraulic hose.
* 5 litre carton of hydraulic ISO32 oilAdaptors and washers to fit hose to cylinder and powerpack.
TECHNICAL DETAILS ON POWERPACK AS FOLLOWS:-
* 1.6kw 24vdc electric motor c/w relay and plastic motor cover.
* 4.3 Litre reservoir c/w drain plug.
* Horizontal mounting Max pressure 220 bar.
* Max flow 4 l/min at 220 bar.
* 24vdc let down valve, relief and P line check.
* Suitable for all single acting applications.
* 2 Button pendent on a 4 metre lead.
TECHNICAL DETAILS ON SINGLE ACTING CYLINDER AS FOLLOWS :-
* Closed Centre pin hole to pin hole 1010mm
* Open Centre pin hole to pin hole 800mm
* Max working pressure 200 bar.
Temperature -30 deg. C to 90 deg C
