The smallest 10,000 watt diesel generator ever
The Smallest 10,000 Watt Diesel Generator EVER! Only 64 dB, Water Cooled, 1800 RRM, only 2.5 x 4.9
10,000 Watt Quiet, Small, No Smoke, Diesel Generator
1-(***)-413-0972 | ****@EmergencyPower.com
The engine consumes less than 0.5 gallons of diesel per hour under full load. It is a clean burning three cylinder diesel engine that has received current year EPA certification. Since it meets new current emission standards it runs cleaner and quieter. The emissions are clear and far better for our environment then older designs.
The engine is based on Isuzu technology and is made by Laidong. The model number is LL380. This is the same engine used in farm tractors and other heavy machinery. It is a slow turning 1800 rpm diesel and water / radiator cooled engine. You can expect a minimum of 10,000 hours life out of it before it requires rebuilding. With proper care you can extend the life indefinitely. Since it uses replaceable cylinder liners, engine overhaul is easier than ever.
* Small Size 4.9' x 2.49' x 2.49'
* Brushless Alternator - Maintenance Free
* Can be used for either 50 or 60 Hz operation ( perfect for export )
* Automatic Voltage Regulator
* Quiet Muffler - generator makes less than 64 db noise.
* Digital Generator Controller
* Powerful 3 Cylinder 1800 RPM Engine
* Battery Included (arrives dry, requires filling)
This generator uses the GU601A microprocessor controlled Automatic Generator Controller. In automatic mode it can be triggered by remote signals such as a loss of power or automatic transfer switch. The LCD display shows generator operational status and parameters. Its main characteristics as below
* Protective parameters can easily be configured via panel input and menu system or by software, USB cable and PC
* Controller can measure and display Alternator Frequency, Alternator Voltage, Battery Voltage, Oil Pressure and Coolant Temperature.
* Set fuel mode to normally closed or normally open mode.
* 5 relay control output Fuel and Start Crank relay outputs
* 3 of the 5 outputs are configurable
* Oil Pressure and Engine Temperature Inputs
* All connections of controller are connected by pin locked up terminals, easier and more convenient to connect, move, maintain and replace the device
AGI10X - 10,000 Watts / 12 kVA Generator
1800 rpm / 60 Hz 1500 rpm / 50 hz
Rated Alternator Output Current
41.7 Amps (240 Volts) 83.3 Amps (120 Volts)
4.9' x 2.5' x 2.5' Enclosed Silent Type
3 Cylinder Water Cooled, 4-cycle, Direct Injection
Not indented for use above 5000 feet
Stamford Type Brushless Alternator with AVR
General maintenance and care is required to insure your generator runs trouble free. Routine oil and filter changes are necessary. Other preventative maintenance may be required such as adjusting fan belts or tightening nuts and bolts. If you have any doubt on your ability to operate, service and maintain a diesel generator, then we recommend you hire or consult with a professional first. You should familiarize yourself with any laws, regulations, building codes or electrical standards in your area that may effect your ability to use this product. We do not rent or resell any used generators. Generator sales are final. Warranties are limited to specific parts replacement only and do not cover labor, sequential damages, negligence or abuse. Never use a generator indoors.
As a result of recent military orders and purchases by Haiti relief organizations our lead time for this product has increased from 2 days to 30 days. We have increased production and expect to be back to our 2 day lead time by mid May. For military orders please refer to D-U-N-S # 206973062 and NCAGE/CAGE L7782
