> Tektronix OTS9040 OC3 -48/ STM1 -16 optical test system
Tektronix OTS9040 OC3 -48/ STM1 -16 optical test system
* Tektronix OTS9040 OC3-OC48/STM1-STM16 Mainframe
* Tektronix 039-0124 CPU Module
* Tektronix OTS91T2 OC192/STM64 Transmitter Module
* Tektronix OTS91C1 OC192/STM64 Clock Trigger Card Module
* Tektronix OTS91L1 OC192/STM64 Tx/Rx Optics Module
* Tektronix OTS91R2 OC192/STM64 Receiver Module
Tektronix OTS9040 OC3-OC48/STM1-STM16 Optical Test System
- OTS91T2 OC192/STM64 Transmitter Module
- OTS91C1 OC192/STM64 Clock Trigger Card Module
- OTS91L1 OC192/STM64 Tx/Rx Optics Module
- OTS91R2 OC192/STM64 Receiver Module
OTS9040 OC3-OC48/STM1-STM16 Mainframe
The OTS9040 Optical Test System provides high measurement capacity. Seven application slots on one cPCI bus segment are available for measurement boards. Modules with high power consumption are supported by the high-performance power supply and cooling system. The system slot is equipped with a cPCI PC board with a Pentium processor. Additionally, the PC board provides one free PMC slot. Thus, one optional PMC module, such as a GPIB module, can be installed. The portable mainframe provides the special supply voltages and interconnections between adjacent slots (THRU-bus and up/down local) required by optical test boards. A complete operator interface is provided to support applications based on Microsoft Windows 2000. Side access is provided for CD Read-Write and floppy drives. A parallel printer connector is available on the rear panel; optionally, an external monitor and keyboard/mouse can also be connected. Additionally, ethernet, USB and serial interfaces are available.
* GPIB, SCSI, Ethernet, CD-ROM Drive, Floppy Drive
* Tektronix OTS9000 Software v6.1
* Tektronix OTS9000 Manual and Release Notes on HDD
* Harware Required: Keyboard and Mouse
OTS91T2 OC192/STM64 Transmitter
OTS91C1 OC192/STM64 Clock Trigger Card
OTS91L1 OC192/STM64 Tx/Rx Optic
