Eagle DHT5-240 hot food table, 5 well, 79" length, elec
Hot Food Table, 5 Well, 79" Length, Electric, 240V
Hot Food Table, electric, 79" L, (5) 12"x20" (dry) wells w/infinite controls, stainless steel top w/8" poly cutting board, galv undershelf & tubular legs, adjustable feet, 240v/60/1-ph, 3750w, 15.7 amps, NEMA 6-30P
* Table body and top are constructed of highly polished 22 gauge 430 series stainless steel
* Top features die stamped beaded openings measuring 12 3/32" x 20 3/32"
* Poly cutting board 8" wide and 1/2" thick mounted on stainless steel brackets located on control side of unit
* Legs are galvanized steel
* All models are 30 1/2"wide and 34" high.
* Individual infinite controls offer high and low selections along with eight other temperature settings for peak performance
* Indicator light remains on continuously while control is in "ON" position
* Each heat compartment is 8" deep and lined with 22 gauge galvanized steel
* Each compartment is insulated on all four sides and bottom with 1" thick fiberglass or equal
* Each compartment is fitted with a 500-watt or 750-watt tubular element above the insulated bottom 500-watt elements is standard on units wired for 110-120 volts 750 watt elements is standard for units wired for
* A six-foot cord with plug will extend from the bottom of the right hand control side as standard equipment
* All models are single phase. 3-Phase available for 240-volt models only (not supplied with cord and plug)
* UL-, NSF-, and CSA-approved
