Associated research 5002D ground bond tester refurbed
Associated Research 5002D Ground Bond Tester Refurbed
The Associated Research 5002D Ground Bond Tester is used for ground bond tests done to insure a low resistance path exist between the safety ground pin of a three wire line cord and exposed metal of the DUT.
* Output current: 3 to 25 A (User Adjustable)
* Failure detector: Audible and visual
* Dwell timer: 0 to 99 seconds in one second increments
* Milliohm meter: 050.0 to 199.9 digital
* Ammeter: 03.00 to 19.99 digital
