Vulcan 936RX griddle, countertop, gas, 36" wide x 24" d
Griddle, Countertop, Gas, 36" Wide x 24" Deep, (81,000 BTU), 1" Thick Plate, Snap Action Thermostat, Electric Spark or Manual Ignition
Heavy Duty Gas Griddle, 81,000 BTU, 36"W x 24"D x 1" thick polished steel griddle plate, embedded mechanical snap action thermostat every 12", millivolt pilot safety, electric spark or manual ignition, countertop, low profile, stainless steel front, sides, front top ledge, front grease trough, grease can, back & tapered side splashes, 4" adjustable legs, CSA, NSF
* Stainless Steel front, sides and 4" top ledge
* Fully welded stainless and aluminized steel body frame
* 11" low profile cooking height on 4" adjustable legs
* 1" thick polished steel griddle plate welded to stainless steel back and tapered side splashers
* 4" back splash with tapered side splashes
* One 27,000 BTU U shaped aluminized steel burner for every 12" of griddle width
* One embedded mechanical snap action thermostat per burner
* Temperature adjusts from 200 degrees to 550 degrees F
* One pilot safety valve for every two burners. Safety will completely shut off gas to pilot and burners if pilot extinguishes
* Dual (manual/electric) ignition
* 3 1/2" wide stainless steel front grease trough
* Large capacity 6 7/" x 30" deep x 2 1/2" high stainless steel grease drawer
* 120v single phase electric ignition circuit with NEMA 5-15 USA plug
* Manufacturer: Vulcan-Hart
