Ryobi 2800 cd + ae swing-away t-51 + crestline + powder
* Crestline Continuous Dampening System
* Crestline Dampener Installed
* Super Blue Anti-Tracking System
* 'New' Rollers Installed
* 'New' Blanket Installed
* Many more features outlined in the 'ITEM FEATURES' area below.
* Condition: This is in showroom condition. Professionally maintained and serviced. This press has had one operator since new, the owner of the business. This press is loaded with great features and options, many of which are upgrades from the standard system available from the manufacturer currently. Great running press that will really pump out work!
* This press is perfect for general one- and multi-color printing applications.
* Run dense solids, high-quality halftone screens and duotones on a variety of stocks in sizes ranging from 3" x 5" to 8-1/2" x 11-3/4" and weights from 12 lb bond to 135 lb index.
* Crestline: Obviously an amazing dampening system. You'll be glad you've got a Crestline when you're running this press. *New Cost: $4500*
* Anniversary Edition Townsend T-51 Second Color Head: The T-51 AE Second Color head from Townsend incorporates: Ductor Shut-Off, Ink Roller clean up attachment, Cylinder separation, Crestline Continuous Dampener and On-The-Fly horizontal and vertical adjustments! *New Cost: $7500*
* Chain Delivery / Receding Stacker
* The Crestline is a completely automatic continuous dampening system.
* The Crestline delivers a carefully metered, thinner film of dampening solution to the plate.
* This film is AUTOMATICALLY adjusted and only the ink keys need be adjusted to maintain denser solids and sharper halftones.
* Maximum Paper Size: 12" x 17" (305 mm x 432 mm)
* Minimum Paper Size: 3" x 5" (76.2 mm x 127 mm)
* Paper Weights: 12 lb. Bond-135 lb. Index (45-244 gm2)
* Paper Thickness: .0025" to .012" (.06 x .30 mm)
* Printing Speed: 3,000 to 10,000 IPH
* Plate Clamp Type: Pinbar / Straight Edge - Paper / Metal / Polyester
* Feeding System: Direct Feed; 6 stationary front blowers; 11 vacuum feed tubes
* Feeder Pile Capacity: 20-1/4" (514.3 mm)
* Delivery Pile Capacity: 22-1/2" (571.5 mm)
* Gripper Margin: 1/4" (6.3 mm)
* Lateral Image Adjustment: 1/4" (6.3 mm)
* Vertical Image Adjustment: 12" Overall (305 mm)
* Angular Image Adjustment: 1/8" (3.1 mm)
* Power Consumption: 1.2kW
