Clean air prod CAP577 vertical flow cleanroom filter
This listing is for a Clean Air Products modular cleanroom filtration system. This is for the filtration system only. The actual walls will need to be purchased from CAP. Please call or email me if you need their contact information.
* Power: 120V / 33.4A / 60Hz / Single Phase
* Overall Dimensions: 74-1/2" x 30" x 30"
Here is the basic info on this series of cleanrooms. Please note that SOME INFORMATION MAY VARY.
Series 577 Vertical Flow Softwall Modular Cleanroom The CAP577 soft wall and rigid wall cleanrooms are a cost-effective method of providing quality particulate control enclosure. The system utilizes proven cleanroom manufacturing and design techniques to provide a lightweight, lowcost, easy-to-assemble cleanroom system. A variety of sizes and shapes are available to ensure a system that is matched to individual needs. These rooms are USP 797 compliant.
The cleanrooms are available from Class 100,000 to Class 10. They typically operate as positive pressure enclosures but can also be used as negative pressure containment areas to HEPA filter all the outgoing room air.
The lightweight, easy-to-assemble sections have a maximum size of 8 ft. x 10 ft. with a leg on each corner. Larger units can be constructed by simply attaching on standard room components to create one continuous room with support legs on an 8 ft. x 10 ft. pattern. A 16 ft. x 20 ft. room would have one center post; a 20 ft. x 32 ft. would have three center posts. The rooms can be expanded or reduced in size without taking the entire cleanroom down. This feature makes it fast and easy to add sections or change the shape for other requirements. A number of smaller rooms can be combined for a large clean room project and later be changed back to smaller rooms and relocated.
Clean Air Product's spec page is located at http:// /cleanrooms/softwall-cleanroom/series577.html
This is used, but in good condition. It is guaranteed to be working. But please note that it will need to properly cleaned, possibly decontaminated, etc., before installation.
