50W 5V dc 10A regulated switching power supply [K019]
50W 5V DC 10A Regulated Switching Power Supply [K019]
K019-HS-50W-5V-10A-1.jpg k019 picture by hpstore2008
* AC input range selectable by switch.
* Protections: Short circuit /Overload / Over voltage.
* High efficiency and low operation temperature.
* Soft-start current can reduce the AC inpur impact effecticly.
* PWM control and regulated.
* 100% full-load burn-in test.
* Installed with EMI filter, minimum wave.
* Fixed switching frequency at 27KHz.
* Low price and high reliability.
85 132VAC/170 264VAC selected by switch 240 370VDC
COLD START 18A/115VAC 36A/230VAC
Protection type: Fold back current limiting, recovers automatically after fault condition is removed.
-10 +60 (Refer to outputload derating curve)
10 500Hz, 2G 10min./1cycle, period for 60min. Each alongX,Y,Z axes
1/p-0/p:1.5KVAC 1/P-FG:1.5KVAC 0/P-FG:0.5KVAC
1/p-0/P, 1/P-FG,0/P-FG:100M Ohms/500VDC
Design refer to FCC part15 J Conduction ClassB
408.3K hrs min. MIL-HDBK-217F(25 )
1.All paramenters NOT specially mentioned are measured at 230VAC input, ratedload and 25 of ambient temperature
2.Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3.Tolerance:includes set up tolerance, line regulation and load regulation.
