Speedaire 80 gallon 3 phase air compressor 162343
80 GALLON 3 PHASE AIR COMPRESSOR
HP RATING: 10.0 HP, FREE AIR FLOW @ 175 PSI: 34.8 CFM, MAXIMUM PRESSURE: 175 PSI, PHASE: THREE, VOLTAGE RATING: 230/460, CURRENT RATING: 26.8/13.4 AMPS, TANK CAPACITY: 80 GALLONS, TANK TYPE: VERTICAL, OIL CAPACITY: 4 QUARTS, SPEED: 740 RPM, HEIGHT: 66-3/4", LENGTH: 42-1/2", WIDTH: 30", NPT OUTLET: (F) 3/4" NPT, INCLUDES MOTOR STARTER, AFTERCOOLER, VIBRATION ISOLATORS, AUTO DRAIN, AIR COOLED AFTERCOOLER REMOVES 60% OF MOISTURE FROM COMPRESSED AIR, VIBRATION ISOLATORS INSULATE COMPRESSOR FROM THE FLOOR TO REDUCE NOISE, DIMS: 65" H X 42" W X 30" D, WEIGHT: 725 LBS, COUNTRY OF ORIGIN: USA
MINOR DAMAGE TO PRESSURE SWITCH COVER, PRESSURE GAUGE IS UNDAMAGED
