Omega engineering psi gague model pgr-65L-10000
Type T: High Accuracy and Monel Wetted
Highly accurate gauges designed for use in instrument shops, plants of all types, and laboratories throughout industry. They provide sustained accuracy to 0.25% full scale for most models. Performance, reliability and precision measurement are coupled with consistent accuracy in meeting the demanding service needs of numerous test gauge applications. These gauges are often used as master reference gauges, in test stand measurements, for production inspection, and for verifying the accuracy of general service gauges. They have a stainless steel mirror ring for pointer reflection to prevent parallax error. This mirror surface reflects the pointer in any position and allows the gauge to be read with great accuracy.
Case:Solid Aluminum with Epoxy coated Black Finish | Window: Glass; | Movement: Stainless Steel; | Bourdon Tube: Monel | Connection: Monel; | Fitting: 1/2 in NPT; | Dial: Externally adjustable, aluminum, white background, black graduations and polished mirror band; | Accuracy: 0.25% FS; | Ring (depending on model): threaded aluminum or Mounting Flange with Hinged Cover Ring Secured by Knurled Screw; | Mounting: Stem.
LET US KNOW IF YOU HAVE ANY QUESTIONS. WE OFFER A DOMESTIC DOA WARRENTY THANKS FOR
