Protek oscilloscope/ multimeter/usb handheld scopemeter
Portable Oscilloscopes / Handheld Multimeter
The pocket size digital storage oscilloscope fulfills basic electronic engineering requirements.
The Pocket Oscilloscope is primarily used in the following situations apply:
1. To go out on-site repair common electronic equipment (air conditioning or industrial frequency inverter power supply, AC / DC switching power supply or inverter, elevators and building fire-fighting equipment, industrial field control circuit)
2. Hardware maintenance or software debugging RS232, RS485, I2C, CAN and other communications interface circuits, LED display and keyboard scan driver circuit, brushless motor drive circuit
3. Audio devices and circuits, electronic toys and remote control models, car repair electronic circuits.
4. School teaching practice and student extra-curricular development of e-small-production
5. Need to observe the signal changes slowly applications (such as: relay and switch contacts jitter, battery charge and discharge curves, regulated power supply load transient response, the temperature sensor characteristics of measurement)
6. Supply the electronic circuit (silicon voltage, power factor compensation, electronic energy-saving lamps, sodium lamps mercury xenon lamp Dysprosium lamp drive circuit, etc.)
ds10-1.jpg picture by sallyboll
It is particularly worth mentioning is that this pocket-sized internal battery-powered oscilloscope can be used, so in situ measurements, the ground is completely suspended, and can be completely the same as the multimeter, which measured points which, without regard to ground isolation issues.
No disappointment, this Pocket Oscilloscope system functions very well!
Handheld Personal Scope
UK/US/AU/EU charging adaptor
Insulated measurement probe x1 / x10
Kingston 2GB MicroSD Flash Card
Built-in Li-ion rechargeable battery
Support at Option software programs upgrades
If Speedpost use that is 3 to 6 work days arrived. The cost is US 18.99 Thanks for understanding.
This product has 100 days warranty.
We accept All damaged/ defective items must be reported within 7 days upon receiving the items.
The item will be carefully and well packed before despatch.
