Giardina G80/01 colour correction roller
rubbered application on roll with infinitely adjustable single drive. hard-chromium-plated reverse running doctor roll tilting rake belt transport table with infinitely variable drive rubbered counter pressure roll diam. 240mm. lacquer supply - double membrane pump material return running piperake tiltable at the application roll for quick cleaning clutch for parallel adjustment of the doctor roll clutch of application roll - change system application roll - return turning for manual cleaning of rolls ******************************************** Technical details: roller width 1580 mm working width 1500 mm passing height approx. 3-80 mm diam. application roll 240 mm diam. counter pressure roll 240 mm doctor roll diam. 165 mm speed of doctor roll approx. 2-10 m/min. application roll drive approx. 075 kW doctor roll drive approx. 075 kW Transport-drive approx. 075 kW smoothing unit ****************** roller width 1580 mm diam. 165 mm drive approx. 11 kW steel - smoothing roll complete with cleaning rake. After filling the steel application roll the lacquer presses into the pores and into the wood connections so that a complete sealed surface will be reached. The adjustable speed of the smoothing roll defines the fine adjustment of the lacquer application as well as the lacquer quantity. length 1100 mm width: 2800 mm height: 1800 mm
