Magnetic stripe id security credit card encoder writer
MSE-730 is a durable commercial grade Lo-Co magnetic card reader & writer with a MTBF of 95,000 hours and the durability of half million swipes on the magnetic head. It reads and writes up to three tracks of information with a single swipe. After every swipe, the data are sent to the computer via standard RS232 serial interface. This Lo-co configurable encoder is specially designed for value added resellers (VARs) and system integrators (SIs). It supports a rich set of commands to interoperate with Windows based software programs.
* MSR206/MSE-630A dual platform compatibility
* ISO 7811-1/2/3/4/5 & ANSI 4.16 1983 compliant
* 5/6/7BPC 210/75BPI on any track
* Dual status indicators - LEDs and beeper
* Durable ABS plastic housing for heavy duty usage
* Operating Voltage: +5V DC ( 5%)
* Current Consumption: 85 mA (read) and 280 mA (write)
* Dimensions (mm): 212 x 63x 63
* Weight: 0.58 kg (1.28 lbs)
* Operating Temperature: 0 to 40 C
* Storage Temperature: -20 to 70 C
* Relative Humidity: 20% to 90% (non-condensing)
