Ab plastic injector model ab-100-4
AB Plastic Injector Model AB-100-4
referencing AB Plastic Injector Model AB-100-4
AB Plastic Injector Model AB-100-4
Technical Specifications: * S/N - 960327
* Voltage: 120, Single Phase
* Shot Capacity: 1/4oz (6grams)
* Injection press,@ 125PSI: 6333PSI
* Temperature range: 100 F-600 F
* Daylight between mold opening: 2" to 2-1/4"
* Maximum molding area: 3 sq. inches
* Cycle Time: Varies due to operator efficiency
* Ram Diameter: 9/16 (14.28mm)
* Hopper Capacity: 7.85oz(220grams)
* Machine Dimension: 18"x21"x25"
* Machine Weight: 70.4lbs. (32KG)
Machine Features: * Easy to read & adjust digital temperature controller
* Adjustable ram speed control
* Aircraft spec. aluminum body
* Easy view material hopper
* Stainless steel injection chamber & piston for corrosion resistance
* All pneumatic devices are of the "no-lube" design; ideal for medical & other clean room applications
* Working area protected by transparent safety-guard and safety red heat shield
* Right & left hand operation
* Quick acting clamp for easy operation
* Hardened screw & bronze nut for long wear
ANY QUESTIONS? SEND EMAIL TO ADDRESS HIGHLIGHTED BELOW
Contact Cliff Davis at 401.724.3200 during normal business hours (EST) or email ****@goldmachinery.com referencing AB 100-4 Plastic Injector.
