Tektronix 2755AP spectrum analyzer 10 khz to 21 ghz
Here is a Tektronix 2755AP spectrum analyzer. It covers a 10 KHz to 21 GHz range. Looks like it can use external mixers to go all the way to 325 GHz.
It has Marker and Center Frequency readout on the screen. Resolution filters from 100 Hz to 1 MHz in decade steps. Video filter range 0.3 Hz to 30 KHz.
Direct plot capability using the IEEE-488 port (it supports HP and Tektronix plotters according to the setup menu).
I have played around with it some, using the built-in CAL source and an RF generator (max freq = 520 MHx). Looks like it's working fine. I can't check it above
520 MHz however. It picks up FM radio stations with a whip antenna and by using the Y output on the back, you can listen to them (slope decoding, tuning off
to the side of the carrier frequency). I in no way checked out all of it's functions. Digital storage works. It passes it's power on test along with it's built in CAL test.
It includes a manuals for the model 2755 / 2755P. Probably close enough. This user manual appears to cover all of it's functions that I could find.
I lucked into a nice Advantest analyzer with a color LCD so this one has to go. Sorry for the poor photos. On the first one, the camera flash washed out the screen
and reflected off the front panel. The screen shot is a little out of focus. In any case, the screen is nice and bright.
and to a confirmed address only.
