South bend 14" gear head lathe manual parts list
14-Inch Gear Head Parts List and Manual
This is a reproduction, not a photocopy, of an original South Bend 14-Inch Gear Head Parts List and Manual. This manual contains information on lubrication, adjustments, maintenance, and controls as well as a complete parts list with exploded view diagrams. This manual is very complete for a South Bend, because all of the attachments and lathe parts are for this model only. The nice thing is they put them all in the same manual, unlike the 9-24 series. The manual section is very detailed and important, because of unique things on this lathe. The parts section is very detailed and laid out in a nice arrangement. I wish all of the South Bends were setup this way.
General Information.....................................1-4
Operations..................................................5-7
Lubrication..................................................8-9
Maintenance............................................10-12
Base and Bed..........................................13-15
Drive Unit................................................16-19
Headstock..............................................20-25
Gear Box................................................26-29
Apron.....................................................30-33
Saddle...................................................34&35
Compound Rest.....................................36&37
Tailstock................................................38&39
Taper Attachment...................................40&41
Follower and Steady Rest..............................42
Turret......................................................43-47
Electrical..................................................48-50
