> MM74C48N - cmos - bcd-to-7 segment decoder
MM74C48N - cmos - bcd-to-7 segment decoder
MM74C48N - CMOS - BCD-to-7 Segment Decoder.
The MM74C48 BCD-to-7 segment decoder is a monolithic complementary MOS (CMOS) integrated circuit constructed with N- and P-channel enhancement transistors. Seven NAND gates and one driver are connected in pairs to make binary-coded decimal (BCD) data and its complement available to the seven decoding AND-OR-INVERT gates. The remaining NAND gate and three input buffers provide test-blanking input/ripple-blanking output, and ripple-blanking inputs.
Made by National Semi. 16 pin Dip case. Look at the picture.
