Lot (50) kobiconn 16PJ031 switched power jacks 5.5X2.1
Only THREE lots of FIFTY available!
Offered here are lots of fifty premium grade DC power jacks that include single disconnect switches.
Switching is highly useful for automatic power changeover or charger current limiting.
Many of these appear to be Kobiconn part number 16PJ031. These can also be direct soldered for thru-hole pc mount. Alternately, they can be superglued in place and direct wired. Apparently intended for the popular 5.5 mm outside diameter, 2.1 mm inside diameter dc power plugs widely used on wall warts.
Noryl black plastic with silver plated brass contacts. Inner pin is 7.5 mm long.
Power jack approximates a 3/8 inch cube. Contacts rated 1 amp.
Some units appear to be a competitive and apparently compatible product of DP-2F TP/4340002 by uElect. The exact shape of the pins are slightly different. Both types should be fully interchangeable. Both have identical footprint and accept the same plug. You normally will receive all of one type per lot. and, if possible, per order.
Guaranteed usable. Power jacks received in "as new" and apparently unused condition, may include minor storage cosmetics.
for the first lot of 50 and $1.00 extra for each additional lot of 50. AZ residents add 8.1% sales tax.
