42" tbl 1HP spdl bridgeport j vertical mill, step-pulle
42" Tbl 1HP Spdl Bridgeport J VERTICAL MILL, Step-Pulle
42" Table 1HP Spindle Bridgeport J VERTICAL MILL, Step-Pulley J-Head, Servo Power Feed, Chrome Ways,
MODEL: J, S/N: 169628, NEW: 1976
TABLE WORKING SURFACE ............ 9" X 42"
NUMBER OF T-SLOTS ................ 3
LONGITUDINAL, POWER ......... 26-1/2"
CROSS ....................... 12"
VERTICAL, KNEE .............. 16"
QUILL ....................... 5"
MIN/MAX DISTANCE, SPINDLE NOSE
TO TABLE .................... 2.5"/18.5"
MIN/MAX DISTANCE, CENTERLINE OF SPINDLE
TO FACE OF COLUMN ........... 6.75"/18.75"
RAM TRAVEL ....................... 12"
HEAD TILT, LEFT & RIGHT .......... 90 DEGREES
HEAD TILT, FRONT TO REAR ......... 45 DEGREES
(3) POWER QUILL FEEDS ............ .0015, .003, .006 IPR
(8) SPINDLE SPEEDS ............... 80-2,720 R.P.M.
SPINDLE TAPER .................... R-8
MAXIMUM COLLET CAPACITY .......... 3/4"
- MODEL J MILLING HEAD, S/N J176084
- SERVO PRODUCTS CO. POWER FEED FOR LONGITUDINAL TRAVEL OF TABLE
- MANUAL ONE-SHOT LUBRICATION SYSTEM
- .75-1 H.P. 1/60/115-230 VOLT SPINDLE DRIVE MOTOR AND ELECTRICAL CONTROLS
- MACHINE IS WIRED FOR 230 VOLT OPERATION.
