> Hardinge dv-59 metal lathe operator's manual DV59
Hardinge dv-59 metal lathe operator's manual DV59
This is a reproduction, not a photocopy, of an original Hardinge Model DV-59 Metal Lathe Operator's Manual. This manual contains information on lubrication, operation instructions, adjustments, and maintenance. See index below.
Belts To Adjust Tension.................4
To Replace .............................9Brake....................................5 To Adjust..............................5 To Replace Insert......................5Cleaning Machine ........................2Collet Closer To Adjust ................8 To Remove..............................7 To Replace.............................8Collet Key..............................10Compound Slide Rest......................6 Tooling Dimensions....................22Coolant Facilities (optional) ..........11Drive Unit...............................3Electrical Connections...................2Floor Plan for Machine .................22Foundation for Machine...................2Installation Instructions................2Leveling Machine.........................2Lifting Machine..........................2Lubrication Brake .....................5 Compound Slide Rest....................7 Spindle Bearings.......................4 Variable Speed Vertical Screw........2,4Regular Equipment for Machine...........21Serial Number............................7Specifications for Machine ............21Spindle Free ..........................4 Lock Pin ..............................8 Speed Change .........................4Tailstock................................6Taper Nose Tooling - To Apply...........10Tooling (optional)......................12 Bed................................17,18 Compound Slide Rest ...............16,17 Headstock Spindle.....................12 Tailstock.............................19
