25" chk 15HP spdl heald 361 rotary surface grinder, son
25" Chk 15HP Spdl Heald 361 ROTARY SURFACE GRINDER, SON
25" Chuck 15HP Spindle Heald 361 ROTARY SURFACE GRINDER, SONY DRO,
25" CINCINNATI-MILACRON HEALD HORIZONTAL SPINDLE
MODEL: 361 S/N: 42581 NEW: 1968
CHUCK FACE DIAMETER..................... 24 7/8"
CHUCK'S MAGNETIC DIAMETER............... 24"
MAX. SWING INSIDE COOLANT PAN........... 28"
STANDARD WHEEL SIZE..................... 14" X 1.5" X 5"
MINIMUM WHEEL DIAMETER.................. 9"
DISTANCE TOP OF CHUCK/GRIND WHEEL....... 4.5 T0 17.5"
MAX ANGLE CONVEX/CONCAVE................ 17/10 DEGREE
TABLE TRAVEL............................ 16"
GRINDING STROKE......................... 12"
CHCUK SPEEDS............................ 38-100 RPM
WHEEL SPEED............................. 1765 RPM
TABLE SPEEDS FOR GRINDING/RUNOUT........ 0-15 FPM/20 FPM
POWER FEED ADJUSTMENT................... .0001" - .0006"
MOTORS MAIN/COOLANT/WHEEL............... 15 HP/ 1/2 HP/ 15
DIMENSIONS.............................. 115" X 79" X 7' 4" H
WEIGHT.................................. 12,000 LBS.
FEED BOX PROVIDES AUTO INCREMENTAL DOWNFEED OF THE WHEEL
INFINITELY VARAIBLE CHUCK SPEEDS
25" ELECTRO-MAGNETIC CHUCK W/CHUCK CONTROL
* * LOW HOURS FROM AIRLINE HUB MAINTENANCE FACILITY * *
* * INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE * *
