Rosback auto stitcher + 3 knife trimmer + very nice
* Serial Number: 203R86758
* Two Interlake Champion Stitching Heads Included
* *New Cost* $1,500 Each
* Serial Number: 250R831547
* Many Extra Cutting Blades
* This is the nicest Rosback system we've ever had come through our doors! It is in great condition and is extremely clean. This machine will make the new owner very happy!
* A Rosback Saddle Binding System will get you up and running fast and keep you running profitably. Our complete parts inventory, personal technical service support and global distribution will keep your commercial printing, in-plant printing, quick print or trade bindery operation efficient. Get production rates that let you control job timing for maximum profit. Invest in the name trusted for over 120 years... ROSBACK.
These fully automatic stitch plus 3-knife trim systems deliver professionally finished books at production speeds. These modular systems were engineered for ease of make-ready, operation and changeover. If you print multiple signature impositions, fold sheets into sigs (4, 8, 12, 16, 24, 32 pages), and your runs range from 500 to 32,000 books per day you will substantially build your profits with Rosback Saddle Binding Systems.
Two to four stitching heads (Interlake, Bostitch, Hohner or ISP) can be used.
Rosback s single book, shear action 3-knife trimming is the most accurate in the industry. Each knife has its own built-in clamp, assures a square 3-edge trim. Several trimmer models are available to cover a wide range of finished sizes.
* The 3-knife trimmer delivers professionally finished booklets that are shingled onto a delivery table.
* All three knives use shear action for square, clean cuts and longer life. Books are trimmed one at a time to insure accuracy and eliminate nicking covers or splitting spines.
* Up to 4 stitching heads can be used at one time. Stitcher heads adjust for 2-1/8 minimum to 9-3/4 maximum spacing, center to center.
* Electric eye and clutched heads prevent stitching unless signature is on the saddle.
* Books can be straight or stagger stitched for easier stacking and boxing of completed work.
* Six top loading pockets permit continuous feeding of signatures or pre-inserted signatures.
* Air blast and mechanical action opens and inserts signatures one inside the other. The collated signatures are placed onto the saddle stitcher.
* Station bottom assemblies give support to light-weight paper stock, especially for 4-page and 8-page signatures.
* Central control panel permits pushbutton operation of feeding, stitching and trimming functions for easy setup and operation.
* Min Finished Book: 4 (10 cm) x 7 (18 cm)
* Max Finished Book: 11-1/2 (29 cm) x 15 (38 cm)
* Max Trim Thickness: 3/8 (9.5 mm)
* Min Overlap (Lip): 1/4" (6.35 mm)
* Min Stitch Spacing (Center to Center): 2-1/8 (5.4 cm)
* Standard Cycle Speeds: 1800 to 5000
* Length: 13 3-1/2 (4.04 m)
* Height: 68-1/2 (174 cm)
* Weight: 4680 lbs. (2123 kg)
