20" w 47" l blohm hfs-512 surface grinder, auto idf, 3X
20" W 47" L Blohm HFS-512 SURFACE GRINDER, AUTO IDF, 3X
20" Width 47" Length Blohm HFS-512 SURFACE GRINDER, AUTO IDF, 3X AUTO FEEDS, EMC, COOLANT
22" X 48" BLOHM "HIGH-PRECISION" (WEST GERMAN) SURFACE
MODEL: HSF-512 S/N: 3314 NEW: 1968
GRINDING CAPACITY ....................... 22" X 48"
TABLE CLAMPING SURFACE .................. 20" X 75"
MAX. DISTANCE TABLE TO SPINDLE CENTER ... 30.5"
CROSS MOVEMENT OF TABLE ................. 20"
LONGITUDINAL MOVEMENT OF TABLE .......... 55- 1/2"
AUTOMATIC ELECTRIC CROSS FEED ........... 0.08" TO 2.5"
LONGITUDINAL TABLE SPEED ................ 6.5' TO 82'
STANDARD MAGNETIC CHUCK ................. 20 X 48"
GRINDING SPINDLE SPEED .................. 1700 RPM
GRINDING WHEEL MOTOR .................... 11 H.P.
GRINDING WHEEL SIZE ..................... 14" X 4" X 5"
APPROXIMATE MACHINE WEIGHT .............. 15,200 LBS
AUTOMATIC INCREMENTAL DOWNFEED FOR SURFACE AND
ELECTRO-MECHANICAL POWER CROSS TRAVERSE
POWER RAPID CROSS TABLE POSITIONING
HIGH PRECISION BALL BEARING ASSEMBLIES FOR TABLE
AND SADDLE RUNNING IN HARDENED GROUND AND LAPPED
FINE DOWNFEED OF VERTICAL FEED GRADUATION TO
20" X 47" FINE-DIVISION ELECTRO-MAGNETIC CHUCK
LATE MODEL O.S. WALKER SMART SERIES VARIABLE HOLD
**** EXCEPTIONAL CONDITION ****
