Mitsubishi hc-SFS202 servo/ motor sumitomo cyclo 2KW
Mitsubishi HC-SFS202 Servo/ Motor Sumitomo Cyclo 2KW
This is a used Mitsubishi Brushless Servo Motor, model number HC-SF202G2 and Sumitomo Cyclo Drive, model number ANFJ-L30-SV-9. Both items are in excellent cosmetic condition. The Sumitomo drive is equipped with a 6-3/4" diameter x 2" wide cog belt drive.
No testing was performed on this item, as we do not have the controller needed to operate it. The identification tag on the motor indicates that it operates on 146 volts, 3 phase.
The HC-SFS series of Brushless servo motors have been developed with the following
* Short body design for installation in confined spaces
* Medium inertia design suitable for direct drive applications requiring peak torque ratings up to 50 Nm
* Maintenance-free 3 phase brushless construction
* Encoder commutation facilitates Sinewave drive technology to provide smooth operation and high resolution of 131072 counts/rev.
* High thermal dissipation characteristics for cool running
* High peak torque provides high acceleration & deceleration capability
* Capable of withstanding factor 2 emergency shock loads without damage
* Low backlash construction provides accurate positioning and long life
* High torsional rigidity for stable operation in high speed positioning
* Low torque ripple for smooth operation in velocity servo applications
* Planetary construction for high torque to volume ratio
* High reliability and serviceability
* Frame Size ( square ) 176mm
* Body length with brake 193mm
* Height to motor connector 142mm
* Typical Flange thickness 18mm
* entering Spigot Length 3mm
* Encoder body length 39.5mm
* Encoder connector position 19.5mm
* Motor connector position 68.5mm
* Motor connector housing 46mm
* Mounting hole diameter 13.5mm
* Shaft Diameter 35mm +0.010 / 0
* Diameter across corners 230mm
* Maximum Continuous Speed 2,500 rpm
* Integral encoder dual track, resolution: 131072 counts per rev.
* Enclosure totally enclosed, protected to IP65, self cooling
* Ambient temperature range 0 to + 40 deg. C
