50 amp plasma cutter 200A tig stick arc welder 190A
3 in 1 IGBT Inverter Welder with Pilot Arc Plasma Cutter
DUAL VOLTAGE/ Tig 200a / Stick 190a /Cutter 50a
_______________________________________________________________________
Portable (DC) Multi Purpose Welder with 50-amp Plasma Cutter
Robust Infineon (By Siemens) IGBT Power Drive Matrix
with PILOT ARC Plasma Cutter
208/220vac 50/60HZ Input Single Phase 1PH
Thermal and Overload Protection
Oversized Cooling Fan to Regulate Temperature.
3" Per minute @ 1" Steel (Severance Cut)
7" Per minute @ 3/4" Thick Steel
17" Per minute @ 1/2" Quality Cut
50 Amps Plasma cutter: Duty Cycle 60% at 50 Amps Works in both 50 and 60 Hz with operating air pressure as 65 psi @ 3 cfm.
200 Amps Tig Welder: Duty Cycle 60% at 200 Amps
190 Amps Arc/Stick Welder: Duty Cycle 60% at 190 Amps
50a Plasma Cutter: Duty Cycle 60% at 50 Amps
Will weld all stainless steel.
Will not weld alloy/aluminim
High Frequency and Contact Start:
Pilot arc / High Frequency DC Plasma cuts thicker materials than standard DC plasma cutters. This 50amp Inverter Plasma cutter cuts like a 60amp standard DC plasma cutter!!! High Frequency Plasma cuts faster with less distortion in your metal.
Weight: 45Lbs(52LBS Boxed)
Air Regulator with Bracket
Please take a look at the picture of all accessories.
!! GUARANTEED AGAINST DOA OR WE WILL EXCHANGE FOR FREE !!
!! GUARANTEED AGAINST DOA OR WE WILL EXCHANGE FOR FREE !! !!
* Please add 8.5% TAX to all CA sales
* For returns, contact must be made within 48 hours of delivery so an RMA number is issued. If there is damage, we can help file a damage claim immediately. However, the damage must be reported within 48 hours of delivery
* DOA items: In an even you will get non working unit , we will exchange it free of charge.
* Items returned must be in an DECENT condition. We will inspect all returns before accepting the package. We will not accept packages that have missing parts, damages, and packages that have not been approved for return by our initial contact or packages missing an RMA number. These packages will be refused and sent back to YOU at your cost.
