Hp agilent 6477C/003 power supply
HP Agilent 6477C/003 Power Supply
The 6477C SCR-regulated power supply is designed for meduim to high-power applications requiring a fixed or variable dc source with moderate regulation and ripple. All supplies in this series are of the constant voltage/constant current type. Large easy-to-read panel meters continuously monitor output voltage current.
Input and output power, remote sensing, remote programming, and auto-series, -parallel, and -tracking connections are made to bus bars and terminal blocks on the rear panel.
* Constant-Voltage/Constant-Current type
* Provides a DC output from 0 to 220 V @ 0 to 50 A
* Reverse voltage protection
* High Tempurature protection thermostat opens input to power transformer and lights front panel indicator if supply overheats
* Prolonged overlad protection circuit is activated and lights front panel indicator if output current exceeds approximately 115% of maximum rating
* Large easy-to-read meters continuously monitor output voltage and current
* Option 003 = 460 Vac 10%, 3-phase, 25 A/phase
