Galil dc i/o controller box ioc-7007 w/7 modules+cables
Galil DC I/O Controller Box IOC-7007 w/7 Modules+Cables
This is a Used Galil DC I/O Controller Box Kit Model IOC-700. This set was pulled from a working machine that was decommissioned by a semiconductor company. This controller is customizable with a variety of module options. This setup includes the controller, 7 Modules, and cables. Cosmetically, the item is in good condition with some minor scratches. No testing was done. The photos show the actual item for sale. Only what is shown in the photos is included.
* Install up to seven plug-in "IOM" modules to handle many input and output functions.
* This unit includes Modules:: (3) IOM-70808, (1) IOM-70908, (1) IOM-70508, (1) IOM-70404, (1) IOM-70108
* Able to "Mix and Match" I/O modules to meet specific requirements
* I/O modules for: 16 TTL Inputs, 8 optoisolated inputs 8 optoisolated outputs, 8 high power outputs, 4 dry contact relays, 8 analog inputs, 8 analog outputs
* Interfaces with other Galil motion controllers or I/O devices via Ethernet
* Ethernet 10/100 Base-T with auto-negotiate function for communicating with 100 Base-T or 10 Base-T devices; One RS232 port up to 19.2kb
* Supports MODBUS in both master and slave mode for interface to other MODBUS devices.
* 8 multitasking threads for simultaneous execution of multiple I/O programs. One additional thread for PLC mode
* PLC mode for fast I/O scans with deterministic timing
* Fast command processing time-less than 100 microseconds
* Non-volatile memory includes 500 line x 80 chr program space; 126 symbolic variables; 1000 elements in up to 14 arrays
* 20-pin molex connectors for easy interface to I/O modules
* (3) IOM-70808 Analog Input Modules
* (1) IOM-70508 High Side Output Module
* (1) IOM-70908 Analog Output Module
