Concrete mixer - 12 cubic yard


PLANS (BLUEPRINTS) TO BUILD A CONCRETE MIXER 12 CUBIC YARD CAPACITY VOLUMETRIC - You are purchasing a set of plans (blueprints) to build this mixer or have someone else build for you!
Mix any amount of Concrete with a push of a button. Mix what you want, when you want. This Mixer is designed with simplicity in mind. Gravel and Sand bins on each side with the center bin holding the cement. Bottom feed chains pull the material out to the mixing auger. Mixing auger (screw) moves the material up and out the discharge end. No conveyor belts to wear out. For clean up, simply shut off the feed chains, start up the auger and wash it out.
THIS MIXER IS A PROFESSIONALLY DESIGNED UNIT...IF YOU HAVE ANY FABRICATION SKILLS YOU WILL BE ABLE TO BUILD.
IF YOU WERE TO PURCHASE THIS MIXER IT WOULD COST OVER $40,000.00
YOU HAVE THE PERMISSION TO BUILD THIS UNIT AND SELL IT AND MAKE EXTRA MONEY.
PLANS TO BUILD YOUR OWN CONCRETE CEMENT MIXER. This is a Commercial type Mixer with professional construction plans. With this mixer one can go into business mixing and pouring concrete. Additional gizmoplans are available for the production of precast products.... such as ..Planters, Picnic tables, Benches, parking stop curbs, concrete steps, PLUS MANY MORE ON gizmoplans. These plans are complete with Bill of Material for all purchased parts, detailed piece part and assembly drawings.Mix what you want when you need it..Auger mixes the material as it is conveyed up and out. This mixer has electric drive motors but can be converted to hydraulic drives easily. Drive chains in the bottom of the hoppers feed the sand,stone and cement into the mixing auger.Water is then added into the Mixing auger. There are control gates to increase or decrease the amount of sand and gravel to change the cement ratio.
1.) One-Man....Push button Operation provides continuous or intermittent concrete mix.
2.) Unique pre-mix unit gives total control & consistent concrete blend.
3.) Easy Loading Hoppers......Simple operating controls.
4.) Aggregate Hoppers...12 cubic yard total...one 6 cubic yard sand bin...one 6 cubic yard gravel bin.
5.) Cement hopper 55 bag capacity
6.) Mix up to 20 cubic yards of concrete per hour.
7.) Water supply 40 PSI...1 supply line.
8.) Mixing auger is 12 diameter and 12 feet long with replaceable wear liners.
9.) Electric winch for raising and lowering the mixing auger.
10.) Overall length...Including mixing auger is 22 feet....Overall height 10 feet..Width is 8 feet.....Approx. weight (empty) 8,000 lbs.
* Over 100 individual drawings
* Large welding assembly layouts.
* Many have converted these plans to hydraulic for use in areas without electrical power
