8 door access control kit with 1200LB lock and software
http://hosting.kyozou.com/spinzter/final%20logo%202.jpg
8 door Access control kit with 1200lb lock and software
This is a turnkey solution to control one door.
This Kit includes the following Items:
Access control eight door networking controller
* Eight door Controller Should deploy sub-door controller or special card reader
* Controlling 8 independent doors and connecting with 16 card readers outside
* Each door has inlet & outlet mark, super lightning proof and 100% water proof
* Loging 9421 ( Exandable) users and storing18,724 records
* Power: DC7-35V; Power consumption <1W
* Input power supply: Inside switch power supply, input power: AC220V/50HZ
* Communication Mode: Standard RS485 or TCP/IP Communication Protocol
* Working temperature: 20 /60 C
* Relative Humidity: 5% - 90%
The multiple language and true 32-bit software package that runs
under Windows 98, 2000, NT and XP, Vista and is for all Proximity Access Control
This is a dedicated software program that provides communication port selection,
data collection, system components physical connection, and all the controller s parameter
settings. With the TCP/IP remote access ability, this feature can support remote location
configuration and data collection. Through the NetBEUI protocol and Local Area Network, the
Server Computer and Client Computers can be spread throughout many offices and buildings;
authorized users can monitor the system by using either Server Computer or Client Computer in
The software program that dedicates the software tools for Door Access Control,
Time & Attendance, Payroll, Elevator Control, Car Park Control, Access Records Reports, Time
& Attendance Daily/Monthly Reports, Projects Management and Operators Authority Level
Control. System also provides with the ability to import bitmap files for photos.
Access Control Network Multi-Door sub Controller
* EM card reader specially used for multi-door controller, also named integrated door device
* With standard functions of card reader
* According to the instructions of the main controller to drive door lock, connect card reader outside and exit button, door magnetism, infared, smoke sensors and fire protection.
* With entry/ exit data and RS485 communication, suitable for long distance wire connectiong up.
* Dimensions: L114mm * W75mm*H17mm
* Working Frequency: 125KHz/13.56 MHz
* Working Temperature: 20'C/60'C
* Reading Speed: Less than 0.1 second
* Operating Distance: EM 50 - 150mm
* IP adress setting: have export address code dial switch
Electric Magnetic Door Lock 1200lb
- Dual voltage 12 or 24 VDC (Selectable)
- Dimensions: 10 1/2" X 3" X 1"
GANG BOX SIZE PUSH-TO-EXIT BUTTON
This illuminated button is mounted on a metal plate that can be secured to a wall near the door it effects. The wide operating temperature range makes it suitable for a number of environments.
* Durable stainless steel plate
* 1M cycles min. rated switch life
* 1.2W lamp, 12VDC (60V max.)
