NEW Shimaden Temperature/Humidity Digital Control SR64
This is a New Shimaden SR64-1Y1-02-0060C Temperature/Humidity Controller. This item was received by a semiconductor company no longer in business. Cosmetically, the unit is new and flawless. The photos are of the actual item for sale. Only what is shown in the photos is included.
* Digital display: 7 segments / Measured value (PV) Red LED 4 digits, Set value (SV) Green LED 4 digits
* Display accuracy: (1/3% FS+1 digit) at 23 5 C Refer to Table of Measuring Range Codes.
* Display resolution: Depends on measuring range (0.001, 0.01, 0.1, 1)
* Action display / colors: 7-type LED lamp indication:
* Control output (OUT) / Green, Higher limit alarm (AH) / Red, Lower limit alarm (AL) / Red,
* Event / Heater break alarm (EV / HB) / Red, Auto tuning (AT) / Green, Manual control (MAN) /
* Red, Set value bias (SB) / Green
* Setting: By 6 front key switches
* Setting range: Same as measuring range
* Setting limit: Higher / lower limits individual setting as desired within measuring range (lower limit value < higher limit value)
* External resistance: 100? max.
* Input impedance: 500k? min.
* Burnout: Standard feature (up scale)
Cold junction temperature compensation accuracy: 2 C (5~45 C)
* R.T.D. : JIS Pt100 / JPt100 3-wire type (Multi range: Refer to Table of Measuring Range Codes.)
* Lead wire tolerable resistance: 5? max. / wire
* Voltage: 10~10, 0~10, 0~20, 0~50, 10~50, 0~100mV DC or 1~1, 0~1, 0~2, 0~5, 1~5, 0~10V DC
(Multi input, programmable range: Refer to Table of Measuring Range Codes.)
* Input impedance: 500k min.
Isolation: Insulated between input and output (not insulated between input and system, SV bias and CT input)
* Control mode: Auto-tuning PID
* Proportional band (P): Off, 0.1~999.9% FS (Off setting: On-Off action)
* Integral time (I): Off, 1~6000 sec. (Off setting: PD, P action)
* Derivative time (D): Off, 0~3600 sec. (Off setting: PI, P action)
* Manual reset (MR): 50.0~50.0% (valid when I=Off.)
* On-Off hysteresis: 1~999 unit
* Proportional cycle: 1~120 sec.
* Higher and lower output limit: 0.0~100.0% (lower limit < higher limit)
* Control output type / rating
* Contact output (Y1): 240V AC 2.5A / resistive load
* Current output (I1): 4~20mA DC / load resistance: 600 max.
* SSR drive voltage output (P1): 15 3V DC / load current: 20mA max.
* Voltage output (V1): 0~10V DC / load current: 2mA max.
