> Hamilton lathe/miller instructions & parts manual
Hamilton lathe/miller instructions & parts manual
Hamilton Lathe/Miller Instruction
This is a reproduction, not a photocopy, of an original Hamilton Lathe/Miller Instruction And Parts Manual. This manual contains information on lubrication, adjustments, maintenance, and controls as well as a complete parts list with exploded view diagrams.
Introduction.....................................................................1 & 2
Specifications.........................................................................3
General Operating Instructions...........................................4&5
Parts Catalog Index................................................................7
Lathe Assembly...............................................................8 & 9
Spindle Assembly........................................................10 & 11
Carriage Assembly......................................................12 & 13
Tailstock Assembly.....................................................14 & 15
Bed Assembly.............................................................16 & 17
Compound Rest Assembly..........................................16 & 17
Milling Machine Assembly...........................................18 & 19
Lifting Screw Assembly...............................................20 & 21
Horizontal Table Assembly..........................................20 & 21
Saddle Assembly.........................................................22 & 23
Knee Assembly...........................................................22 & 23
Fine Hand Feed Assembly...........................................24 & 25
Overarm Assembly......................................................26 & 27
Half Nut Housing Assembly.........................................26 & 27
Motor & Switch Control..............................................28 & 29
Motor & Magnetic Start..............................................30 & 31
Motor & Safety Cut-Off..............................................32 & 33
Motor, Magnetic Start & Safety Cut-Off.....................34 & 35
