New renishaw redhead 5µm linear encoder pn: RGH22R20D00
NEW Renishaw Redhead 5 m Linear Encoder PN: RGH22R20D00
* Non-contact open optical system
* Industry standard digital and analogue output options
* Integral reference and limit sensors
* Power supply: 5 V 5% 120 mA (typical)
* Ripple 200 mVpp @ frequency up to 500 kHz maximum
* Temperature Storage: -20 C to +70 C Operating 0 C to +55 C
* Acceleration Operating 500 m/s BS EN 60068-2-7:1993 (IEC 68-2-7:1983)
* Shock (non-operating) 1000 m/s , 6 ms, sine BS EN 60068-2-27:1993 (IEC 68-2-27:1987)
* Vibration (operating) 100 m/s max @ 55 Hz to 2000 Hz BS EN 60068-2-6:1996 (IEC 68-2-6:1995)
* Cable 12 core, double shield, maximum diameter 4.7 mm. Flex life >20 x 106 cycles at 50 mm bend radius
* Connector: 15 pin D type plug
