Hp agilent 11664A 10MHZ-18GHZ network analyzer detector
HP AGILENT 11664A 10MHz-18GHz NETWORK ANALYZER DETECTOR
SearchBy9 - 14146 | Location: A85 | By: MATTY | Tester: CARL | Quan: 1 | List: 1 | Duplicate? False | Plan: D
Standard Relist: True | Size: 0x0x0 Weight: 3 | MGR: SELF MANAGED LISTING (No MGR) | Start: $0.00 | BIN: $199.99 | Type: Fixed Price
Sales: | Business & Industrial > Electrical & Test Equipment > Test Equipment > Network Analyzers > Modules
The HP Model 11664A Detector must be used in conjunction with the HP Model 8755C Swept Amplitude Analyzer. The 11664A detects RF signal levels from -5G to +10 dBm in the frequency range from 10 MHz to 18 GHz. Use of three 11664A Detectors enables simultaneous (amplitude only) transmission and reflection measurement via the 8755C Analyzer/ 180-series Display.
The 11664A Detector and the unput stages of the 8755C comprise an ac-coupled system. This detection scheme requires 27.8 kHz squarewave modulation of the RF input signal.
