1993 matsuura mc-800V-dc-PC2 dual spdl vmc w/pallets
1993 MATSUURA MC-800V-DC-PC2 DUAL Spdl VMC w/PALLETS
1993 MATSUURA MC-800V-DC-PC2 DUAL SPINDLE VMC w/PALLETS
PALLET DIMENSIONS............... 35.43" x 17.71"
NUMBER OF PALLETS............... 2
PALLET LOAD CAPACITY............ 1102 LBS.
PALLET CHANGE TIME.............. 23 SECS.
AXIS TRAVELS X - AXIS........... 31.5"
PALLET SURFACE TO SPINDLE END... 6.89" - 26.97"
SPINDLE TAPER................... BT #40
SPINDLE SPEED................... 6000 RPM x 2
SPINDLE MOTOR................... 10HP EACH SPINDLE AC
SPINDLE DRIVE SYSTEM............ GEAR DRIVE/2 STEPS
RAPID TRAVERSE.................. 590 IPM X,Y 472IPM Z
CUTTING FEEDRATES............... .1" - 196"
DIST. BETWEEN SPINDLES.......... 16"
MAX. TOOL DIAMETER.............. 6.8"
MAX. TOOL WEIGHT................ 26 LBS.
MAX. TOOL LENGTH................ 12"
COOLANT THRU SPINDLE READY - NO PUMP
