Avanex powerreach transponder 10GB tunable 50GHZ 80-km
AVANEX PowerReach TRANSPONDER 10GB TUNABLE 50GHz 80-Km
Avanex PowerReach TTRX-1280 Transponder, 10GB 300-Pin MSA, Tunable, 50GHz, 80km, 10GE Transponder
The PowerReach 1280 300-pin MSA transponder operates at the OC-192, STM-64, and 10 GE data rates. It also operates in 10Gb/s systems with Forward Error Correction (FEC), increasing the bit rate operation up to 11.3Gb/s. The 16-bit electrical interface operates at 1/16 bit rate. The module is housed in a 300-pin standard package with common electrical interfaces. As part of the Avanex 10 Gb/s LFF Transponder family, the PowerReach 1280 TRX provides convenient and flexible optical interfaces for 50GHz spaced DWDM systems. The performance of the 1280 exceeds the applicable optical transmission standards, namely, ITU-T G.691, ITU-T G.709, Telcordia GR-253 and OIF SFI4-01.0 standards. The transmitter can integrate either a full C-band or an L-band continuous wave laser connected to an external LiNbO3 modulator, while the receiver side can integrate a Pin or an APD receiver (APD-VOA in option).
* Full C & L-Band Tunable Transponder
* NRZ and Optical Duobinary (ODB) Configurations Available
* Multi-source Optical Interfaces
* I C Bus with 300-PIN MSA Protocol
* Lower Spacing 50 GHz Applications
* Optical Rate from 9.9 -11.3 Gb/s, Electrical Rate: 1/16 of Bit Rate
* Full Performance in Operating Case temperature from - 5 to + 70 C.
* Standard Package: 3.5x4.5x0.5 in3
* Avanex Reliability and Qualification Program for Built-In Quality
* Power Consumption: 7 W Typical (@25C)
Optical Output Power (Typ) +5.5 dBm
Extinction Ratio (Min) 12 dB
PIN Receiver Sensitivity (Max) -16 dBm
APD Reciever Sensitivity (Max) -24 dBm
Dispersion (zero chirp) 800 ps/nm
Dispersion (pre-chirp) + or - 1600 ps/nm
Operating Case Temp -5 to +70 C
