6" W 18" L Okamoto 6X18 PFG-618 SURFACE GRINDER, Fine F
6" Width 18" Length Okamoto 6X18 PFG-618 SURFACE GRINDER, Fine Feeds on Vertical and Cross, Roller T
6" X 18" OKAMOTO "LINEAR 618""HIGH-PRECISION"
MODEL: PFG-618 S/N: 8250U NEW: 1989
WIDTH & LENGTH GROUND .......................... 6" X 18"
TABLE TO SPINDLE CENTER ............................. 18"
HEIGHT UNDER 8" WHEEL TO CHUCK SURFACE .............. 11"
LONGITUDINAL TABLE TRAVEL ........................... 14"
CROSS TRAVEL ......................................... 8"
GRINDING WHEEL CAPACITY ........... 8" X 1" X 1-1/4" BORE
(.001" GRAD.) .................................... 0.100"
CROSS FEED HANDWHEEL VERNIER READS TO............ 0.0001"
PPROX. WEIGHT ................................ 1,500 LBS.
APPROX. DIMENSIONS ..................... 58" X 46" X 71"H
FINE FEED KNOB FOR CROSS AXIS, .0001" GRAD.
FINE FEED KNOB FOR VERTICAL AXIS, .00005" GRAD.
6" X 18" WALKER CERAMAX FINE-DIVISION PERMANENT MAGNETIC
