Aoyue 768 3 in 1 digital hot air rework repair station
pictures and contents of this listing is copyright to usaunlocker.
1 Brand New factory sealed box OEM Original
AOYUE 768 Hot Air 3 in1 Repair Rework Soldering Station for repairing or building digital circuit boards used in digital devices such as digital cameras, mobile phones and modern electronics.
An ideal combination of essential tools.
Most practical workstation in the world.
This is a 3 in 1 Digital hot air station with a soldering iron and a built-in external power supply. Long Life heat Element All digital controls 1.5 A/ 0-15 V power supply 500 watt metal heater 45 Watt soldering iron 15 minute stand-by auto sleep mode programmable auto reworking time from 20 to 9999 seconds Quick heat up Temperature range 100-480 C (212-896 F) Air Flow 23L/min (max) Main station with hot air gun, Air nozzles (1124,1130,1197, 1313, 1919),G001 IC popper, Z003 Hot air gun holder, Soldering Iron with Tip, Soldering Iron Holder with Solder Wire Stand, Spare soldering iron element, DC connecting wire, vacuum suction pen, Power cord.
Professional cell phone repair shop
Digital/Analog electronics repair shop
Popular science hobbyist and many many more.
One station does it all. Aoyue 768 combines the featuers of hot air, soldering station, 15 V DC power source and 2A current sipply in full digital display. Reworking period can be set automatically from 20 to 9999 seconds. The microprocessor design system provides stability and precision of temperature and airflow settings during rework process.
* CPU Controlled, fully digital display.
* Automatic hot air gun welding time.
* 2A, 15V power supply. Provides accureate and stable electric source.
* Hot air welding and adjustment of sldering tempreatuera are controlled by micro chip and sensor thus giving out accurate and reliable temperature and airflow.
* Self-testing device. When power is turned on and is not being used within ten minutes, the unit goes to sleep mode. Returns to previous setting when system is held again.
Soldering Iron Output Voltage: 24V / 35W
Temperature Range: 100 - 480 C
Pump Type: Special Purpose Diaphragm Pump
Air Capacity: 23 L/min (maximum)
Hot air gun: Metal heating core
Soldering Iron: Ceramic heating core
Dimensions: 187 (w) x 135 (h) x 270 (d) mm
* 768 Repairing System (Main Unit) (a)
* Mobile phone power supply connector (e)
* 939 vacuum suction pen (g)
* Air nozzles (BGA-L, M, 1124, 1130, 1197) (h)
* Spare soldering iron heating element (j)
As we stand behind our products!
