0.375" Cap. 144" Width Cincinnati 3DL x 12' SHEAR, 36" Front Operated Power Back Gauge
12 x ? CINCINNATI Hydraulic Power Squaring Shear
Model 3DL x 12 S/N 39382 NEW 1974
Nominal capacity at 9/32 rake 12 x ?
Maximum capacity at 7/16 rake 12 x
Length between housings 12 3
Normal holddown force 26 Tons
Distance under each holddown 1
Speed for full length cutting 24 SPM
Speed for 24 length cutting 50 SPM
36 capacity front operated power backgage
Built-in ball transfers in table
(12) Floor mounted ball transfers
30 H.P. 3/60/220-440 volt motor with controls
Approximate weight: 33,200 lbs.
Dimensions: 14 7 L x 86 W x 9 2 High from floor level
Requires: 8 depth of pit for bed
