Falcon - falcon bottle top shrink tunnel tun-1230
NEW IN BOX Falcon Whole Bottle Shrink Tunnel
FALCON SHRINK TUNNEL MOD. TUN-1230
The shrink Stainless Steel tunnel TUN-1230 supplies heated air to an enclosed chamber for the purpose of shrinking a polymeric film around a package for physical protection and improve the appearance of containers or products. This tunnel includes an electronically controlled conveyor for carrying packages through the chamber.
* Whole Bottle Shrink System
* Optimal Label Shrinkage, Positioning, and Presentation
* High Density Roll Conveyor for Optimal Container Balance
* Full Shrinkage from All Sides, Including Bottom
* Adjustable Tunnel Temperature
* Tunnel Dimensions: 59" (1500mm) x 4.7" (120mm) x 11.8" (300mm)
* Conveyor Speed: (12 mtrs/hr)
* Aprox. Output: 8,000 " 12,000 pcs/hr
* Maximum Bottle Size: (100mm x 280mm H)
* Whole System Speed Control via Stepless Speed Controller
* Casters for Ease of Movement
Tunnel Path Dimensions: L 59 (1500mm) x W 4.7 (120mm) x H 11.8 (300 mm)
Machine Dimensions: L 71 (1800mm) x W 24 (600mm) x H 59 (1550mm)
Machine Weight: 584 lbs (226 Kg)
Box Dimensions: L 71 (1450mm) x W 29 (840mm) x H 68 (1120mm)
